| Focal Length: | 14-54mm Focal length (equiv. 35mm) 28 mm - 108 mm |
| Lens configuration: | 15 lenses/11 groups |
| Aspherical glass elements: | 3 |
| Lens Mechanism: | Inner focus with floating mechanism |
| Angle of View: | 75 - 23 ° |
| Closest focusing distance: | 0.22m |
| Maximum image magnification: | 0.26 x (Four Thirds) / 0.52 x (35mm format) |
| Number of aperture blades: | 7 |
Maximum Aperture: | 1:2.8 (wide)/1:3.5 (tele) |
| Minimum Aperture: | 1:22 |
| Filter Diamater: | 67mm |
| Dimensions: | 4.5 mm X 88.5 mm |
| Weight: | 440g |
| Compatibility: | EX-25, EC-20, EC-14 |
