Angle of view (horzntl, vertl, diagnl) | 5°10', 3°30', 6°10' |
Lens construction (elements/groups) | 7/6 |
No. of diaphragm blades | 8 |
Minimum aperture | 32 |
Closest focusing distance (m) | 3.5 |
Maximum magnification (x) | 0.12 |
AF actuator | USM¹ |
Filter diameter (mm) | 77 |
Max. diameter x length (mm) | 90 x 256.5 |
Weight (g) | 1,250 |
Magnification - Extension Tube EF12 II | 0.16 - 0.03 |
Magnification - Extension Tube EF25 II | 0.21 - 0.07 |
Lens hood | - |
Hard case | LH-D29 |
Soft case | LZ1132 |
