Angle of view (horzntl, vertl, diagnl) | 6°50', 4°35', 8°15' |
Lens construction (elements/groups) | 15/11 |
No. of diaphragm blades | 8 |
Minimum aperture | 32 |
Closest focusing distance (m) | 1.5 |
Maximum magnification (x) | 0.24 |
AF actuator | USM |
Filter diameter (mm) | 77 |
Max. diameter x length (mm) | 90 x 221 |
Weight (g) | 1,190 |
Magnification - Extension Tube EF12 II | 0.30 - 0.04 |
Magnification - Extension Tube EF25 II | 0.37 - 0.09 |
Lens hood | - |
Hard caseHard case | LH-D27 |
Soft case | LZ1128 |
