| IMAGE SENSOR |
| Type | 36 x 24 mm CMOS |
| Effective Pixels | Approx. 21.1M |
| Total Pixels | Approx. 21.9M |
| Aspect Ratio | 3.2
|
| Low-Pass Filter | Built-in/Fixed |
| Sensor Cleaning | EOS integrated cleaning system with fluorine coating |
| Colour Filter Type | Primary Colour |
| | |
IMAGE PROCESSOR |
| Type | 2 x DIGIC III |
| | |
| LENS |
| Lens Mount | EF (excludes EF-S lenses) |
| Focal Length | Equivalent to 1.0x the focal length of the lens |
| | |
FOCUSING |
| Type | TTL-AREA-SIR with a CMOS sensor |
| AF System/ Points | 19 cross-type AF points (plus 26 Assist AF points) |
| AF Working Range | EV -1 - 18 (at 23°C & ISO 100) |
| AF Modes | One Shot
AI Servo |
| AF Point Selection | Automatic selection, Manual selection, Home position (switch to registered AF point) |
| Selected AF Point Display | Superimposed in viewfinder |
| Predictive AF | Yes, up to 8m ¹ |
| AF Lock | Locked when shutter button is pressed half way in One Shot AF mode or AF-ON button is pressed. |
| AF Assist Beam | Emitted by an optional dedicated Speedlite |
| Manual Focus | Selected on lens, default in Live View Mode |
| AF Microadjustment | C.Fn III-7
+/- 20 steps
Adjust all lenses by same amount
Adjust up to 20 lenses individually |
| | |
| EXPOSURE CONTROL |
| Metering Modes | TTL full aperture metering with 63 zone SPC
(1) Evaluative metering (linked to any AF point)
(2) Partial metering (approx. 8.5% of viewfinder at centre)
(3) Spot metering:
Center spot metering (approx. 2.4% viewfinder)
AF point-linked spot metering (approx. 2.4% of viewfinder)
Multi/Spot metering (Max 8 spot metering entries)
(4) Center weighted average metering |
| Metering Range | EV 0 - 20 (at 23°C with 50mm f1.4 lens ISO 100) |
| AE Lock | Auto: In One-shot AF mode with evaluative metering exposure is locked when focus is achieved.
Manual: By AE lock button in P, TV and AV modes. |
| Exposure Compensation | +/-3 EV in 1/3 or 1/2 stop increments (can be combined with AEB). |
| AEB | +/-3 EV in 1/3-stop increments. 1/2-stop increments |
| ISO Sensitivity* | 100-1600 (in 1/3-stop or 1 stop increments) ISO can be expanded to L: 50 or H: 3200 |
| | |
| SHUTTER |
| Type | Electronically-controlled focal-plane shutter |
| Speed | 30 - 1/8000 sec. (1/3 stop increments), Bulb (Total shutter speed range. Available range varies by shooting mode) |
| | |
| WHITE BALANCE |
| Type | Auto white balance with the imaging sensor |
| Settings | Auto, Daylight, Shade, Cloudy, Tungsten light, White Fluorescent light, Flash, Custom (5 settings), Colour Temperature Setting
White balance compensation:
1. Blue/Amber +/-9
2. Magenta/ Green +/-9. |
| Custom White Balance | 5 custom WB settings can be registered |
| WB Bracketing | +/-3 levels in single level increments
3 bracketed images per shutter release.
Selectable Blue/Amber bias or Magenta/ Green bias. |
| |
| VIEWFINDER |
| Type | Pentaprism |
| Coverage | Approx. 100% |
| Magnification | Approx. 0.76x ¹ |
| Eyepoint | Approx. 20mm (from eyepiece lens centre) |
| Dioptre Correction | -3 to +1 (1/m) (dioptre) |
| Focusing Screen | Interchangeable (10 types). Standard Focusing Screen Ec-C IV |
| Mirror | Quick-return half mirror (Transmission: reflection ratio of 37:63, no mirror cut-off with EF1200mm f/5.6 or shorter) |
| Viewfinder Information | AF information: AF points, focus confirmation light
Exposure information: Metering mode, shutter speed, aperture, manual exposure, spot metering circle, AE lock, ISO speed, exposure level, exposure warning
Flash information: Flash ready, FP flash, FE lock, flash exposure level
Image information: White balance correction, JPEG recording, RAW recording, number of remaining shots, maximum burst (2 digit display), memory card information, battery check icon. |
| Depth of Field Preview | Yes, with Depth of Field preview button. |
| Eyepiece Shutter | Built-in |
| | |
| LCD MONITOR |
| Type | 3.0"" TFT, approx. 230K dots |
| Coverage | Approx. 100% |
| Viewing Angle | Approx 140° |
| Brightness Adjustment | Adjustable to one of seven levels |
| Display Options | (1)Shooting function
(2) Camera settings |
| | |
| FLASH |
| Modes | E-TTL II Auto Flash, Metered Manual |
| X-Sync | 1/250sec (EX series Speedlites only) |
| Flash Exposure Compensation | +/-3 EV in 1/3 or 1/2 stop increments with EX series Speedlites |
| Flash Exposure Bracketing | Yes, with compatible External Flash |
| Flash Exposure Lock | Yes |
| Second Curtain Synchronisation | Yes |
| HotShoe/ PC Terminal | Yes/Yes |
| External Flash Compatibility | E-TTL II with EX series Speedlites, wireless multi-flash support. |
| External Flash Control | via camera menu screen |
| | |
| SHOOTING |
| Modes | Program AE, Shutter priority AE, Aperture priority AE, Manual |
| Picture Styles | Standard, Portrait, Landscape, Neutral, Faithful, Monochrome, User Defined (x3) |
| Colour Space | sRGB and Adobe RGB |
| Image Processing | Highlight Tone Priority
Long exposure noise reduction
High ISO speed noise reduction |
| Drive Modes | Single, Continuous L, Continuous H, Self timer (2s+remote, 10s+remote), Silent single shooting |
| Continuous Shooting | Max. Approx.5fps. (speed maintained for up to 56 images (JPEG)¹³, 12 images (RAW)) ²³ |
| | |
| LIVE VIEW MODE |
| Type | Electronic viewfinder with image sensor |
| Coverage | Approx. 100% (horizontally and vertically) |
| Frame Rate | 30 fps |
| Focusing | Manual Focus (Magnify the image 5x or 10x at any point on screen)
Autofocus: Quick mode |
| Metering | Real-time evaluative metering with image sensor
Active metering time can be changed |
| Display Options | Grid overlay |
| | |
| FILE TYPE |
| Still Image Type | JPEG: 10 compression options (Exif 2.21 [Exif Print] compliant) / Design rule for Camera File system (2.0),
RAW: RAW, sRAW (14bit, Canon original RAW 2nd edition),
Digital Print Order Format [DPOF] Version 1.1 compliant |
| RAW+JPEG Simultaneous Recording | Yes, any combination of RAW + JPEG possible, separate formats to separate cards possible |
| Image Size | JPEG: (L)5616x3744, (M1)4992x3328, (M2)4080x2720, (S)2784x1856
RAW: (RAW)5616x3744, (sRAW)2784x1856 |
| Sound Files | WAVE (monaural) |
| Folders | New folders can be manually created and selected |
| File Numbering | (1) Consecutive numbering
(2) Auto reset
(3) Manual reset |
| | |
| OTHER FEATURES |
| Custom Functions | 57 Custom Functions with 153 settings |
| LCD Panel / Illumination | Yes |
| Water/ Dust Resistance | Yes |
| Sound Memo | Up to 30sec per image |
| Intelligent Orientation Sensor | Yes |
| Playback Zoom | 1.5x - 10x |
| Display Formats | (1)Single image with information (inc. file size)
(2) Single image
(3) 4 image index
(4) 9 image index
(5) Magnified view |
| Histogram | Brightness: Yes
RGB: Yes |
| Image Erase/Protection | Erase: Single image, All images in folder, Checkmarked images, unprotected images
Protection: Erase protection of one image, all images in a folder, or all images in the memory card. |
| Data Verification | Original image verification data and encryption can be appended to the image (OSK-E3 required for verification + encryption/decryption) |
| Menu Categories | (1) Recording menu (x2)
(2) Playback menu (x2)
(3) Set-up menu (x3)
(4) Custom Functions menu
(5) My Menu |
| Menu Languages | English, German, French, Dutch, Danish, Portuguese, Finnish, Italian, Norwegian, Swedish, Spanish, Greek, Simplified Chinese, Japanese, Traditional Chinese, Korean, Russian, Polish |
| Firmware Update | Update possible by the user. |
| | |
| INTERFACE |
| Computer | USB 2.0 Hi-Speed (Mini-B) |
| Other | Video output (PAL/ NTSC), 15-pin System Extension terminal |
| | |
| DIRECT PRINT |
| Canon Printers | Canon Compact Photo Printers and PIXMA Printers supporting PictBridge |
| PictBridge | Yes |
| | |
| STORAGE |
| Type | CompactFlash Type I/ II (Microdrive compatible)¹, SDHC¹, SD memory (up to 2GB). |
| | |
| SUPPORTED OPERATING SYSTEM |
| PC & Macintosh | Windows 2000 (SP4) / XP (SP2) / Vista (excl. Starter Edition)
OS X v10.3-10.5 |
| | |
| SOFTWARE |
| Browsing & Printing | ZoomBrowser EX / ImageBrowser |
| Image Processing | Digital Photo Professional |
| Other | PhotoStitch, EOS Utility (inc. Remote Capture, WFT utility*), Picture Style Editor
* Requires optional accessory |
| | |
| POWER SOURCE |
|
| Batteries | 1x Li-ion pack LP-E4, 1x CR2025 for date & settings |
| Battery Life | Approx. 1800 (at 23C)¹
Approx. 1400 (at 0C) |
| Battery Indicator | 6 levels + percentage |
| Power Saving | Power turns off after 1, 2, 4, 8, 15 or 30mins. |
| Power Supply & Battery Chargers | Battery charger LC-E4, Car Battery Cable CG-570 (use with LC-E4), Power Adapter ACK-E4 |
| | |
| PHYSICAL SPECIFICATIONS |
| Body Materials | Magnesium Alloy |
| Operating Environment | 0-45 °C, 85% or lower humidity |
| Dimensions (WxHxD) | 156.0 x 159.6 x 79.9mm |
| Weight (Body Only) | Approx. 1210g (battery weight 180g) |
| | |
| ACCESSORIES |
| Viewfinder | Eyecup Eg, Eg-series Dioptric Adjustment Lens with Rubber Frame Eg, Anti Fog Eyepiece Eg, Focusing Screens Ec, Angle Finder C |
| Wireless File Transmitter | Wireless File Transmitter WFT-E2 |
| Lenses | All EF lenses (excludes EF-S lenses) |
| Flash | Canon Speedlites (220EX, 270EX, 270EX II, 320EX, 420EX, 430EX, 430EX II, 550EX, 580EX, 580EX II, Macro-Ring-Lite, MR-14EX, Macro Twin Lite MT-24EX, Speedlite Transmitter ST-E2) |
| Remote Controller/ Switch | Remote control with N3 type contact, Wireless Controller LC-5 |
| Other | Hand Strap E2 |
| | |
Predictive AF | ¹ with EF300mm f/2.8L IS USM at 50kph |
Magnification | ¹ with 50mm lens at infinity, -1(1/m) dpt |
Continuous Shooting | ¹ Large/Fine(Quality 8) resolution
² Based on Canon's testing conditions, JPEG, ISO 100, Standard Picture Style. Varies depending on the subject, memory card brand and capacity, image recording quality, ISO speed, drive mode, Picture Style, Custom functions etc.
³ Maximum fps and buffer capacity may be reduced depending on the cameras settings and light level |
Battery Life | ¹ Based on the CIPA Standard and using the batteries and memory card format supplied with the camera, except where indicated |
Type | ¹ Firmware update required |
* Recommended Exposure Index |
|
