| Type of Camera | Digital camera with interchangeable lenses |
| Lens Mount | Nikon 1 mount |
| Effective Angle of View | Approx. 2.7× lens focal length (Nikon CX format) |
| Effective Pixels | 10.1 million |
| Image Sensor | 13.2 mm × 8.8 mm CMOS sensor |
| Dust-reduction System | Dust shield glass |
| Image Size (pixels) | ill images (still image and Smart Photo Selector modes, aspect ratio 3 : 2) • 3,872 × 2,592 • 2,896 × 1,944 • 1,936 × 1,296 Still images (movie mode, aspect ratio 16 : 9) • 3,840 × 2,160 (1080/60i) • 1,920 × 1,080 (1080/30p) • 1,280 × 720 (720/60p) Still images (Motion Snapshot mode, aspect ratio 16:9) • 3,840 x 2,160 |
| File Format | NEF (RAW): 12-bit, compressed • JPEG: JPEG-Baseline compliant with fine (approx. 1 : 4), normal (approx. 1 : 8), or basic (approx. 1 : 16) compression • NEF (RAW) + JPEG: Single photograph recorded in both NEF (RAW) and JPEG formats |
Picture Control System | Standard, Neutral, Vivid, Monochrome, Portrait, Landscape; selected Picture Control can be modified; storage for custom Picture Controls |
| Storage Media | SD (Secure Digital), SDHC, and SDXC memory cards |
| File System | DCF (Design Rule for Camera File System) 2.0, DPOF (Digital Print Order Format), Exif (Exchangeable Image File Format for Digital Still Cameras) 2.3, PictBridge |
| Shooting Modes | still image (3 : 2), Smart Photo Selector (3 : 2), movie (HD 16 : 9, slow motion 8 : 3), Motion Snapshot (16 : 9) |
| Compatible Lenses | 1 NIKKOR lenses for 1 mount |
| Shutter Type | Electronic Shutter |
| Shutter Speed | 1/16,000-30s in steps of 1/3EV; Bulb; Time (requires optional ML-L3 remote control) |
| Flash Sync Speed | Synchronizes with shutter at X=1/60s or slower |
| Release Mode | Single frame, continuous, Electronic (Hi) •Self-timer, delayed remote, quick-response remote, interval timer shooting |
| Frame Advance rate 1 | Electronic (Hi): Approx. 10, 30, or 60 fps • Other modes: Up to 5 fps (single AF or manual focus, S Shutter-priority auto or M Manual exposure mode, shutter speed 1/250 s or faster, and other settings at default values |
| Self-timer | 2 s, 5 s, 10 s |
| Remote Control Modes | Delayed remote (2 s); quick-response remote |
| Exposure metering | TTL metering using image sensor |
| Metering Method | Matrix • Center-weighted: Meters 4.5 mm circle in center of frame • Spot: Meters 2 mm circle centered on selected focus area |
| Mode | Programmed auto with flexible program; shutter priority auto; aperture-priority auto; manual; scene auto selector |
| Exposure Compensation | –3–+3 EV in increments of 1/3 EV |
| Exposure Lock | Luminosity locked at metered value with AE-L/AF-L button |
| ISO Sensitivity | ISO 100–3200 in steps of 1 EV. Can also be set to approx. 1 EV (ISO 6400 equivalent) above ISO 3200; auto ISO sensitivity control (ISO 100–3200, 100–800, 100–400) available |
| Active D-lighting | on, off |
| Autofocus | Hybrid auto focus (phase detection/contrast detect AF); AF-assist illuminator |
| Lens Servo | Auto focus (AF): Single AF (AF-S); continuous AF (AF-C); auto AF-S/AF-C selection (AF-A); full-time AF (AF-F) • Manual focus (MF)" |
| AF-area Mode | Single-point, auto-area, subject tracking |
| Focus Area | Single-point AF: 135 focus areas • Auto-area AF: 41 focus areas |
| Focus Lock | Focus can be locked by pressing shutter-release button halfway (single AF) or by pressing AE-L/ AF-L) button |
| Face-Priority AF | on, off |
| Built-in Flash | Built-in flash: raised by sliding flash pop-up switch control |
| Guide Number | Approx. 5/16 (m/ft, ISO 100, 20°C/68°F) |
| Flash Control | i-TTL flash control using image sensor available |
| Flash Mode | Fill flash, slow sync, red-eye reduction, slow sync with red-eye reduction, rear-curtain sync, rear curtain with slow sync |
| Flash Compensation | –3–+1 EV in increments of 1/3 EV |
| Flash-ready Indicator | Lights when built-in flash unit is fully charged |
| White Balance | Auto, incandescent, fluorescent, direct sunlight, flash, cloudy, shade, preset manual, all except preset manual with fine tuning |
| Movie Metering | TTL metering using image sensor |
| Metering Mehod | Matrix • Center-weighted: Meters 4.5 mm circle in center of frame • Spot: Meters 2 mm circle centered on selected focus area |
| Frame Size (pixels)/recording rate | HD movies • 1,920 × 1,080/60i (59.94 fields/s*2) • 1,920 × 1,080/30p (29.97 fps) • 1,280 × 720/60p (59.94 fps) Slow-motion movies • 640 × 240/400 fps (plays at 30p/29.97 fps) • 320 × 120/1,200 fps (plays at 30p/29.97 fps) Motion Snapshot • 1,920 X 1,080/60p (59.94fps) (plays at 24p/23.976fps) |
| Maximum Recording Time | 1080/60i (20 minutes)、1080/30p (20 minutes)、720/60p (29 minutes |
| File format | MOV |
| Video Compression | H.264/MPEG-4 Advanced Video Coding |
| Audio Recording Format | AAC |
| Audio Recording Device | Built-in stereo microphone; sensitivity adjustable |
| Monitor | 7.5cm/3-in., approx. 460k-dot, TFT LCD with brightness adjustment |
| Playback Function | Full-frame and thumbnail (4, 9, or 72 images or calendar) playback with playback zoom, movie playback, slide show, histogram display, auto image rotation, and rating option |
| USB | Hi-Speed USB |
| HDMI Output | Type C mini-pin HDMI connector |
| 25 Supported Languages | Arabic, Chinese (Simplified and Traditional), Czech, Danish, Dutch, English, Finnish, French, German, Greek, Hungarian, Indonesian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese, Romanian, Russian, Spanish, Swedish, Thai, Turkish, Ukrainian |
| Battery | One rechargeable Li-ion EN-EL20 battery |
| AC Adapter | EH-5b AC adapter; requires EP-5C power connector (available separately) |
| Tripod Socket | 1/4-in. (ISO 1222) |
| Dimensions (W x H x D) | Approx. 106× 61×29.8mm/4.2× 2.4× 1.2in., excluding projections |
| Weight | Approx. 277 g/9.8oz with battery and memory card but without body cap; approx. 234 g/8.3 oz(camera body only) |
| Temperature | Temperature: 0–40 °C/+32–104 °F/humidity: less than 85% (no condensation) |
| Supplied Accessories | EN-EL20 rechargeable Li-ion battery, MH-27 battery charger, UC-E6 USB cable, EG-CP14 audio/vldeo cable, AN-N1000 strap, BF-N1000 body cap, ViewNX 2/Short Movie Creator CD |
| Still Images | Approximately 230 |
| Movies | Approximately 70 minutes of HD footage at 1080/60i |
