IMAGE SENSOR |
Type | 1/1.7 type CCD |
Effective Pixels | Approx. 10.0M |
Colour Filter Type | Primary Colour |
IMAGE PROCESSOR |
Type | DIGIC 4 with iSAPS technology |
LENS |
Focal Length | 6.1 - 30.5 mm (35 mm equivalent: 28 - 140 mm) |
Zoom | Optical 5x. Digital Approx. 4x (with Digital Tele-Converter Approx. 1.4x or 2.3x and Safety Zoom¹)². Combined Approx. 20x |
Maximum F/number | f/2.8-f/4.5 |
Construction | 11 elements in 9 groups (1 double-sided aspherical element) |
Image Stabilisation | Yes (lens shift-type), 4-stop, Hybrid IS |
FOCUSING |
Type | TTL |
AF System/ Points | AiAF (Face Detection / 9-point), 1-point AF (Any position is available, fixed centre or Face Select and Track) |
AF Modes | Single, Continuous (only available in Auto mode), Servo AF/AE[10], Tracking AF |
AF Point Selection | Manual selection using FlexiZone AF/AE, Size (Normal, Small) |
AF Lock | On/Off Selectable |
AF Assist Beam | Yes |
Manual Focus | Yes |
Focus Bracketing | Yes |
Closest Focusing Distance | 1 cm (W) from front of lens in macro |
EXPOSURE CONTROL |
Metering modes | Evaluative (linked to Face Detection AF frame), Centre-weighted average, Spot (centre or linked to Face Detection AF or FlexiZone AF frame) |
AE Lock | Yes |
Exposure Compensation | +/- 2 EV in 1/3 stop increments Enhanced i-Contrast for automatic dynamic range correction ND Filter (3 stop) |
AEB | 1/3 - 2 EV in 1/3 stop increments |
ISO sensitivity | AUTO, 80, 100, 125, 160, 200, 250, 320, 400, 500, 640, 800, 1000, 1250, 1600, 2000, 2500, 3200 |
SHUTTER |
Speed | 1 - 1/4000 sec. (factory default) 15 - 1/4000 sec. (total range – varies by shooting mode) |
WHITE BALANCE |
Type | TTL |
Settings | Auto (including Face Detection WB), Daylight, Cloudy, Tungsten, Fluorescent, Fluorescent H, Flash, Underwater, Custom1, Custom2. White Balance Correction |
VIEWFINDER |
Viewfinder | Real-image zoom, optical viewfinder |
Dioptre Correction | Yes |
LCD MONITOR |
Monitor | Vari-angle 7.0 cm (2.8”) PureColor II VA (TFT), Approx. 461,000 dots |
Coverage | Approx. 100% |
Brightness | Adjustable to one of five levels. Quick-bright LCD |
FLASH |
Modes | Auto, Manual Flash On / Off |
Slow Sync Speed | Yes. Fastest speed 1/2000 sec. |
Red-Eye Reduction | Yes |
Flash Exposure Compensation | +/- 2 EV in 1/3 stop increments. Face Detection FE. Safety FE. |
Flash Exposure Lock | Yes |
Manual Power Adjustment | 3 levels with internal flash (up to 19 levels with external EX Speedlites 270EX and 430EX II. 22 levels with 580EX II¹) |
Second Curtain Synchronisation | Yes |
Built-in Flash Range | 50 cm - 7.0 m (W) / 4.0 m (T) |
External Flash | E-TTL with EX series Speedlites¹, Macro Twin Lite MT-24EX, Macro Ring Lite MR-14EX, Canon High Power Flash HF-DC1 |
SHOOTING |
Modes | Auto*, Program AE, Shutter priority AE, Aperture priority AE, Manual, Custom (2 modes), Low Light (2.5MP), Quick Shot, SCN (Portrait, Landscape, Kids & Pets, Sports, Smart Shutter(Smile, Wink Self-Timer, FaceSelf-Timer), Super Vivid, Poster Effect, Foliage, Snow, Beach, Fireworks, Underwater, Color Accent, Color Swap, High Dynamic Range, Fish-eye Effect, Miniature Effect, Nostalgic, Stitch Assist), Movie with Scene Detection Technology and Motion Detection Technology |
Photo Effects | My Colors (My Colors Off, Vivid, Neutral, Sepia, Black & White, Positive Film, Lighter Skin Tone, Darker Skin Tone, Vivid Blue, Vivid Green, Vivid Red, Custom Color) |
Drive modes | Single, Continuous, Self-Timer |
Continuous Shooting | Approx. 2.0 shots/sec.¹, AF: Approx. 0.7 shots/sec.¹, LV: Approx. 0.8 shots/sec. (until memory card becomes full) |
RECORDING PIXELS / COMPRESSION |
Image Size | 4:3 - (L & RAW) 3648 x 2736, (M1) 2816 x 2112, (M2) 1600 x 1200, (S) 640 x 480, Resize in playback (M2, S, 320 x 240) 16:9 - (L) 3648 x 2048, (M1) 2816 x 1584, (M2) 1920 x 1080, (S) 640 x 360 3:2 - (L)3648 x 2432, (M1) 2816 x 1880, (M2) 1600 x 1064, (S) 640 x 424 1:1 - (L) 2736 x 2736, (M1) 2112 x 2112, (M2) 1200 x 1200, (S) 480 x 480 4:5 - (L) 2192 x 2736, (M1) 1696 x 2112, (M2) 960 x 1200, (S) 384 x 480 |
Compression | Fine, Normal |
Movies | (HD) 1280 x 720, 24 fps, (L) 640 x 480, 30 fps, (M) 320 x 240, 30 fps Miniature Effect (HD, L) 6fps, 3fps, 1.5 fps |
Movie Length | Up to 4 GB or 29 min. 59 sec. (HD) Up to 4 GB or 1 hour (L, M) |
FILE TYPES |
Still Image Type | JPEG compression, (Exif 2.3 [Exif Print] compliant) / Design rule for Camera File system, RAW, Digital Print Order Format [DPOF] Version 1.1 compliant |
Movies | MOV [H.264 + Linear PCM (stereo)] |
DIRECT PRINT |
Canon Printers | Canon SELPHY Compact Photo Printers and Canon Inkjet Printers supporting PictBridge (ID Photo Print, Fixed Size Print and Movie Print supported on SELPHY CP & ES printers only) |
PictBridge | Yes |
OTHER FEATURES |
Red-Eye Correction | Yes, during shooting and playback |
My Camera / My Menu | Start-up image and camera sounds customisation. Menu customisation |
My Category | Image tagging feature |
Intelligent Orientation Sensor | Yes |
Histogram | Yes, live histogram |
Playback Zoom | Approx. 2x - 10x |
Self Timer | Custom |
Menu Languages | English, German, French, Dutch, Danish, Finnish, Italian, Norwegian, Swedish, Spanish, Simplified Chinese, Chinese (traditional), Japanese, Russian, Portuguese, Korean, Greek, Polish, Czech, Hungarian, Turkish, Thai, Arabic, Ukrainian, Romanian, Farsi |
INTERFACE |
Computer | Hi-Speed USB (MTP, PTP) dedicated connector (Mini-B compatible) |
Other | HDMI Mini Connector (HDMI-CEC compatible) A/V output (PAL/NTSC) |
MEMORY CARD |
Type | SD, SDHC, SDXC, MMC, MMCplus, HCMMCplus |
SUPPORTED OPERATING SYSTEM |
PC & MAC | Windows 7/ Vista SP1-2/ XP SP3 Mac OS X v10.4 - 10.6 |
SOFTWARE |
Browsing & Printing | ZoomBrowser EX / ImageBrowser |
Other | PhotoStitch |
Image Manipulation | Digital Photo Professional for RAW development |
POWER SOURCE |
Batteries | Rechargeable Li-ion Battery NB-7L (NB-7L battery and charger supplied) |
Battery life | Approx. 370 shots Approx. 420 min. playback |
A/C Power Supply | Optional, AC Adapter Kit ACK-DC50 |
ACCESSORIES |
Cases / Straps | Soft Case DCC-660, SC-DC65A, DCC-1600 |
Waterproof / Weatherproof Case | Waterproof Case (40m) WP-DC34, Waterproof Case Weight WW-DC1 |
Lenses | Tele-converter 1.4x TC-DC58D Lens Adapter LA-DC58K Filter Adapter FA-DC58B (Compatible with Canon 58mm Filters: Circular Polarizing PL-C B, Neutral Density Filter ND4X-L & ND8X-L, Protect, UV, Softmat No.1 & 2) |
Flash | Canon Speedlites (including 220EX, 270EX, 430EX II, 580EX II [4]), Macro Twin Lite MT-24EX, Macro Ring Lite MR-14EX, Speedlite Transmitter ST-E2, Off-Camera Shoe Cord OC-E3, Bracket BKT-DC1, Speedlite Bracket SB-E2, High Power Flash HF-DC1 |
Remote Controller/ Switch | Remote Switch RS-60E3 |
Power Supply & Battery Chargers | AC Adapter Kit ACK-DC50, Battery Charger CB-2LZE |
Other | Ring Accessory Kit RAK-DC2 Canon HDMI Cable HTC-100 |
PHYSICAL SPECIFICATIONS |
Operating Environment | 0 - 40°C, 10 - 90% humidity |
Dimensions (WxHxD) | 112.1 x 76.2 x 48.3 mm |
Weight | Approx. 401 g (including battery/batteries and memory card) |
